Natural Gas Fired Metal Melting Furnace Copper With Vesuvius Crucible

Natural Gas Fired Metal Melting Furnace Copper With Vesuvius Crucible

Brand Name:	WONDERY
Model Number:	WR-RCUQ
MOQ:	1 Set
Price:	Negotiable
Delivery Time:	30 Days
Payment Terms:	L/C, T/T

Detail Information

Product Description

Detail Information

Place of Origin:

Jiangsu, China (Mainland)

Certification:

ISO CERTIFICATE

Name:

Metal Melting Furnaces

Furnace Type:

Titling

Furnace Capacity:

300-1000KG

Casting Material Life:

5 Years On Average

Temperature Control Accuracy:

Plus/minus 2 Degree Celsius

Max Furnace Temperature:

1300 Degree Celsius

Packaging Details:

Plywood case suitable for sea transportation

Supply Ability:

10 Sets per Month

Highlight:

metal melting equipment

aluminum melting furnace

Product Description

Natural Gas Fired Metal Melting Furnace Copper With Vesuvius Crucible

Product Description

Natural Gas Fired metal Melting Furnaces for copper is used to melt copper scraps at a temperature of 1250degree celcius.

Natural Gas Fired Metal Melting Furnaces Copper
Fuel	Natural gas	kcal/m3	8400
	Natural gas consumption	m3/ton Copper	80-90
	Gas burner brand		Riello (or decided by customer)
Main performance parameters	Melting cycle	hour	2
	Working temperature	℃	1250
	Crucible brand		Vesuvius
Hydraulic system	components brand		domestic brand

Main Features

1) The copper metal melting furnace is equipped with high quality Riello imported brand burner.

2) The crucible melting furnace is scientifically designed with a chimney.

3) The melting furnace body is built with once-forming casting material which has a life of more than 3 years.

4) The copper melting furnace is designed with an emergency outlet hole in case that the crucible breaks.

5) The copper metal melting furnace is equipped with two thermal couples, 1 for measuring the hearth

temperature and1 for measuring the liquid temperature.

MODEL TABLE of Melting Furnace

Type Number	Crucible Specification			Maximum Melting Rate (kg/h)
Type Number	Inner diameter (mm)	Height (mm)	Capacity (kg)	Maximum Melting Rate (kg/h)
WR-RCUQ-300	455	500	300	200
WR-RCUQ-500	455	600	500	350
WR-RCUQ-800	615	700	800	600
WR-RCUQ-1000	620	800	1000	700

Picture of Continuous Aluminum Metal Melting Furnaces with Charging Device for max 3000kg per hour productivity Natural Gas Fired Metal Melting Furnace Copper With Vesuvius Crucible 0
