WDL-8812 Vacuum High-Temperature Brazing Furnace Graphite Heating – WUXI WONDERY

Product Overview

WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD. presents the WDL-8812 Vacuum High-Temperature Brazing Furnace (Graphite Heating Type) – a large-capacity industrial furnace engineered for high-volume vacuum brazing operations. This system utilizes high-strength graphite heating elements and optimized graphite felt insulation to deliver consistent thermal performance across an 800×800×1200mm working zone at temperatures up to 1300℃.

The WDL-8812 is designed for manufacturers requiring substantial processing capacity with exceptional temperature uniformity. It excels in brazing applications for large stainless steel assemblies, copper components, cemented carbide products, and various non-ferrous metal parts in demanding production environments.

Technical Specifications

Key Features

• High-Capacity Design: 800kg maximum load capacity enables large-batch processing, significantly improving production efficiency and reducing per-unit costs

• Large Working Zone: 800×800×1200mm effective area accommodates oversized workpieces or high-volume loading of multiple components

• Multi-Zone Temperature Control: Independent control zones ensure ±5℃ uniformity throughout the entire working volume, critical for large-part brazing quality

• Robust Graphite Heating: Heavy-duty graphite elements provide reliable performance under continuous high-temperature operation

• Advanced Vacuum System: High-throughput pumping configuration achieves rapid evacuation and maintains 8×10⁻³ Pa ultimate vacuum for clean brazing results

• Efficient Thermal Insulation: Thick-section graphite felt insulation minimizes energy consumption during extended brazing cycles

• Production-Oriented Controls: Industrial PLC system with large HMI display enables comprehensive process monitoring and recipe managemen

Contact WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD. today to learn how the WDL-8812 vacuum brazing furnace can scale your production capacity and meet your most demanding manufacturing requirements!
