Energy Saving Type Electric Power Aluminum Holding Furnace

Energy Saving Type Electric Power Aluminum Holding Furnace

Energy Saving Type Electric  Power Aluminum Holding Furnace
Energy Saving Type Electric  Power Aluminum Holding Furnace

Large Image :  Energy Saving Type Electric Power Aluminum Holding Furnace

Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: WONDERY
Certification: CE CERTIFICATE
Model Number: WR-BJD
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set/Sets
Price: Negotiable
Packaging Details: plywood case suitable for sea transportation
Delivery Time: 30 Days
Payment Terms: L/C, T/T
Supply Ability: 5 Set/Sets per Month
Detailed Product Description
Name: Metal Melting Furnaces Energy: Electricity
Capacity: 3000kg/h Structure: Both Melting And Holding Chamber
Max Furnace Temperature: 1200℃ Temperature Control Accuracy: ±2℃
High Light:

metal melting machine

,

aluminum melting furnace





Energy Saving Type Electric  Power Aluminum Holding Furnace



1. Features



1) Ultra-high heat utilization efficiency, and low power consumption. It saves power consumpstion by more than 40% compared wih the traditional radiation type holding furnace.

2) There is no aluminum liquid burning loss or slag hanging phenomenon.

3) The furnace adopts high quality refractory material with a long lining service life (up to 5 years under normal use condition)

4)  Adopt Japanese imported protective tube which has a long service life, safe and stable.

5)  PID temperature control system with an accuracy of ±2℃.

6) The Control Panel has multiple safety functions such as aluminum liquid over-temperature alarm, atmosphere over-temperature alarm, heater circuit breakage alarm, etc.



 2. Technical Parameters

Model

Holding Capacity (kg)

Rated Power (kw)

Overall Dimension

(mm)

Ladling Size

(mm)

WR-BJD-500

500

12

1800*1400*1400

400*400

WR-BJD-700

700

14

1980*1600*1400

450*450

WR-BJD-900

900

14

2120*1600*1500

500*500

WR-BJD-1200

1200

16

2300*1800*1550

500*500

WR-BJD-1500

1500

21

2600*1800*1600

500*500

WR-BJD-2000

2000

30

2900*2100*1650

600*550

WR-BJD-2500

2500

36

3200*2200*1700

700*700



 Energy Saving Type Electric  Power Aluminum Holding Furnace 0
