Introduction to WDL-JS-1200 Vacuum Impregnation Equipment
The WDL-JS-1200 Vacuum Impregnation Equipment is a powerful, high-performance solution designed to seal porous castings and improve their integrity. This equipment uses advanced vacuum impregnation technology to pressurize a sealant into the pores and cavities of cast metal parts, effectively repairing leaks and enhancing the part's ability to contain liquids and gases. The WDL-JS-1200 is an essential piece of equipment for industries such as automotive, plane and ships where leak-proof performance is critical.

Vacuum impregnation is an ideal method for sealing castings made from aluminum, magnesium, copper alloys, and other metals prone to porosity. This equipment is perfect for applications involving leakage repair, improving insulation properties of electrical components, and preparing parts for galvanizing or plating.

Key Features of WDL-JS-1200 Vacuum Impregnation Equipment

1. High Capacity and Versatility:

   • The WDL-JS-1200 is capable of handling large components with a diameter of up to 1200 mm and an effective height of 1200 mm. This makes it perfect for industries requiring large-scale impregnation for heavy-duty parts.

2. Multi-Stage Impregnation Process:

   • This system utilizes a comprehensive multi-stage impregnation process, including vacuum impregnation, centrifugal drying, two-stage cleaning, and hot water curing, which ensures thorough sealing and consistent results.

3. PLC Automation for Efficient Operation:

   • The WDL-JS-1200 is equipped with a PLC-based control system that ensures precise and automated control over all stages of the impregnation process. This reduces manual labor, minimizes errors, and increases production efficiency.

4. Durable Construction and Long Service Life:

   • Built with high-quality materials and components, the WDL-JS-1200 provides reliable, long-lasting performance even in demanding environments. Its vacuum degree of < 200 Pa ensures excellent sealing and enhances the equipment’s durability.

Vacuum Impregnation Process with WDL-JS-1200

The impregnation process for the WDL-JS-1200 model involves several steps designed to provide the highest quality sealing:

1. Preparation:

   • Clean components are placed into a basket and prepared for the impregnation process.

2. Vacuum Impregnation:

   • The basket is lowered into the impregnation tank, where a vacuum is applied to remove all air from the components and the sealant. The tank is then filled with sealant liquid to completely cover the workpieces. The pressure is then increased to 0.4 MPa, allowing the sealant to penetrate deeper into the micropores.

3. Centrifugal Drying:

   • After impregnation, the parts are moved to the centrifugal drying tank, where excess sealant is removed by rotating the basket in both directions for 3 minutes.

4. Two-Stage Cleaning:

   • The parts are then moved to two wash tanks where they are cleaned with cold water and pneumatic mixing to remove any residual sealant.

5. Hot Water Curing:

   • Finally, the workpieces are placed in a hot water cure tank at 90°C for 15 minutes to solidify the sealant and complete the sealing process.

Technical Specifications of WDL-JS-1200 Vacuum Impregnation Equipment

Note: The WDL-JS-1200 is customizable based on specific customer requirements, allowing for flexibility in handling different types of castings and components.

Why Choose WDL-JS-1200 Vacuum Impregnation Equipment?

1. Optimal Sealing Performance:

   • The WDL-JS-1200 provides superior sealing performance, effectively filling even the smallest voids in castings to ensure leak-proof integrity. This is crucial for applications that require parts to hold gases or liquids under pressure.

2. Enhanced Productivity:

   • With its PLC automation and high throughput capabilities, the WDL-JS-1200 increases production efficiency while maintaining consistency in results, making it an ideal solution for large-scale production environments.

3. Long-Term Reliability:

   • Built with high-quality materials and equipped with durable components, the WDL-JS-1200 guarantees long-term operation with minimal downtime, reducing the need for frequent maintenance and repairs.

4. Flexibility for Large Components:

   • With its ability to handle components up to 1200 mm in diameter and 1200 mm in height, the WDL-JS-1200 is well-suited for industries that deal with large, complex castings.

Conclusion

The WDL-JS-1200 Vacuum Impregnation Equipment is a powerful and versatile solution for industries requiring high-performance sealing of porous castings. With its advanced multi-stage impregnation process, PLC automation, and customizable design, the WDL-JS-1200 ensures efficient, reliable, and long-lasting results for a wide range of applications. Whether you're looking to seal automotive parts, aerospace components, or industrial castings, the WDL-JS-1200 is the ideal choice for your impregnation needs.

For more information or to inquire about the WDL-JS-1200, contact us today and enhance your casting sealing process with cutting-edge technology!
