3000kg Aluminum Electric Metal Melting Furnace Melter

Name: 3000kg Aluminum Electric Metal Melting Furnace Melter
Brand: Wuxi Wondery Industry Equipment Co., Ltd
SKU: WR-CCD-1000/3000
Price: 15.00 USD
Availability: InStock

Product Details

Place of Origin: Jiangsu, China (Mainland)

Brand Name: WONDERY

Certification: CE

Model Number: WR-CCD-1000/3000

Payment & Shipping Terms

Minimum Order Quantity: 1 Set

Price: Negotiable

Packaging Details: plywood case suitable for sea transportation

Delivery Time: 90 Days

Supply Ability: 100 Set/Sets per Year

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                                                3000kg aluminum melting machine, Aluminum electric metal melting furnace, 3000kg electric metal melter


Model:	WR-CCD-1000/3000	Holding Capacity:	1000/3000kg
Rated Power:	27KW/60KW	Rated Temperature:	850℃
Rated Voltage:	380V, 3P, 50HZ	Empty Furnace Temperature Rising Time:	Less Than 3 Hours
Furnace Weight:	About 5Ton/ 8Ton	Furnace Surface Temperature:	Room Temperature + 30℃

Model:	WR-CCD-1000/3000
Holding Capacity:	1000/3000kg
Rated Power:	27KW/60KW
Rated Temperature:	850℃
Rated Voltage:	380V, 3P, 50HZ
Empty Furnace Temperature Rising Time:	Less Than 3 Hours
Furnace Weight:	About 5Ton/ 8Ton
Furnace Surface Temperature:	Room Temperature + 30℃

Product Description

WR-CCD-1000/3000 Electric Aluminum Holding Furnace

1.Main technical Parameters

Model: WR-CCD-1000/3000;

Holding capacity:1000/3000kg;

Rated power: 27KW/60KW;

Rated temperature: 850℃;

Rated voltage: 380V, 3P, 50HZ;

Heating component connection: Y;

Empty furnace temperature rising time; less than 3 hours;

Furnace weight: about 5Ton/ 8Ton;

Furnace surface temperature: room temperature + 30℃;

2. Electrical Control System

2.1 main components

a) heating component: silicon carbon rod (6 pieces per set);

b) control system: temperature controller (Taiwan brand, 2 pieces), electronic power regulator, contactor, relay.

temperature sensing component: thermal coupling (2 pieces in together, 1 for measuring the hearth atmosphere temperature and another for measuring the molten aluminum temperature)

2.2 Electrical control system (PID control)

The thyristors are the main controlling component of the electrical control system. The output current is controlled through the change of the conduction angle of the thyristor. The furnace employs the advanced phase control and firing circuit to control the conduction angle of the thyristor. The temperature controller has various protection functions such as soft start-up, over-current protection and over-temperature protection. When the furnace temperature rises over the upper limit or the current is abnormal due to faults, the controller can automatically stop pulse output, and stop power supply.

2.3 Temperature control accuracy

±5℃( under standard working conditions)

3. Company Info

Wuxi Wondery Trading Co., Ltd is a comprehensive fin radiator making machine supplier. Our company

supplies the following machines: aluminum radiator fin machine, aluminum radiator core builder machine, aluminum

radiator plastic tank clinching machine, aluminum radiator brazing furnace, aluminum radiator leak testing machine,

radiator header plate mold, radiator side plate mold, plastic tank die, etc.
