2000KGS Industrial Immersion Type Electric Aluminum Holding Furnace

2000KGS Industrial Immersion Type Electric Aluminum Holding Furnace

Product Details:
Place of Origin: CHINA
Brand Name: WONDERY
Certification: CE
Model Number: WDL-CDJ-2000
Payment & Shipping Terms:
Minimum Order Quantity: 1 SET
Packaging Details: PLYWOOD CASES
Delivery Time: 3-5 working days
Payment Terms: L/C, D/P, Western Union
Supply Ability: 1000 SETS PER MONTH
Detailed Product Description
Name of equipment: Industrial Aluminum Holding Furnace Furnace Type: Immersion Type
Rated Power: 28KW Holding Capacity: 2000KG
Temperature Control Accuracy: ± 2 ℃ Rated Temperature Of Aluminum Liquid: 730℃
Warranty: 1 Year Furnace Wall Temperature: 20℃ +room Temperature

2000KGS Industrial Immersion Type Electric Aluminum Holding Furnace



1. Product description of aluminum holding furnace


The industrial immersion holding furnace has been upgraded on the basis of the previous generation of

aluminum holding furnace, the structure has been optimized, and a new generation of holding furnace

has been launched after it is stable in practical use.

Immersion aluminum alloy electric insulation furnace is mainly suitable for the holding purpose of

non-ferrous metal liquid. The industrial aluminum holding furnace has high requirements for die-casting

process and low equipment energy consumption.

Direct internal heating of molten aluminum has high thermal efficiency, no oxide, high temperature

control accuracy of molten aluminum, and the energy consumption is more than 60% lower than

that of ordinary radiant heating furnace

Heating elements imported from Europe.


2.Advantages of new generation immersion aluminum holding furnace:

2.1 Intermittent boiler shutdown can be realized and the operation is convenient

2.2 It is more convenient to replace the heating pipe, which can be operated after

on-site basic training

2.3 Longer service life of furnace body

2.4 No burning loss of molten aluminum to ensure the high quality of molten aluminum

2.5 Ultra low energy consumption cost, heating source close to 100% thermal efficiency

2.6 Precise temperature control accuracy (± 2 ℃)




3. Technical Parameters


Model Quantity (set) Rated temperature of molten aluminum (℃) Rated power (kw) Capacity (kg)

Heating capacity

(℃ / h)

Insulation energy consumption


Oxygen content in furnace

WDL-CDJ-2000 1 730 28 2000 40 Less than 8kw / h Less than 2%


4.Steel Structure

The shell of the aluminum holding furnace body is welded and cast by steel plate

and section steel.The whole

furnace has lifting function, which is easy to match with the equipment.

Lining composition:

The molten pool is formed by one-time castable. This castable material is

ACX84 high-strength non stick aluminum

castable, which has the characteristics of high strength, non stick aluminum and

long service life.(compressive strength: 140MPa above 110 ℃, while the linear change rate is only 0.1%).

There is no obvious slagging on the inner wall of the furnace after long-term use.

The furnace top and the upper end of the industrial aluminum holding furnace wall

use the thermal insulation layer, and the imported nano thermal insulation layer.

The temperature rise of the industrial aluminum holding furnace wall is less than

10 degrees. The temperature rise in special areas is within 20 degrees.




5.Electrical component details

No. Item Brand
1 touch screen Kunluntongtai
2 PLC Mitsubishi
3 Heating tube artem
4 Electric energy meter chint
5 Power regulator Taiwan Taisi
6 Molded case circuit breaker Schneider
7 Miniature circuit breaker Schneider
8 Signal lamp Schneider
9 Signal lamp Schneider
10 Signal lamp Schneider
11 Selector switch Schneider
12 Small electromagnetic relay Schneider
13 Small electromagnetic relay Schneider
14 Level relay Schneider
15 Ceramic thermocouple
16 Thermocouple
