Full Automatic Hairpin Bender 8 Lines For Heat Exchanger

Full Automatic Hairpin Bender 8 Lines For Heat Exchanger

Full Automatic Hairpin Bender 8 Lines For Heat Exchanger
Full Automatic Hairpin Bender 8 Lines For Heat Exchanger Full Automatic Hairpin Bender 8 Lines For Heat Exchanger

Large Image :  Full Automatic Hairpin Bender 8 Lines For Heat Exchanger

Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: WONDERY
Certification: CE
Model Number: HSPK45
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood Case or Nude Package Suitable for Sea Transportation
Delivery Time: 30 Days
Payment Terms: L/C, T/T
Supply Ability: 10 Sets per Month
Detailed Product Description
Name: Hairpin Bender Max Tube Expansion Length: 5000mm
Pipe Diameter: φ5-φ15.88 Application: Household Air Contioners
Warranty: 1 Year Bending Line: 4,6,8 Lines
High Light:

Full Automatic Hairpin Bender

,

8 Lines Hairpin Bender

,

Hairpin Bender for Heat Exchanger

Full Automatic Hairpin Bender for Heat Exchanger



1. Application



The hairpin bending machines represent the combination

of the most advanced technology and versatility; each detail

is designed and manufactured to assure reliability, productivity,

accuracy and durability. Furthermore, our industry know-how

has allowed us to overcome all of the critical aspects commonly

associated with the production of hairpins, such as the cutting

shape and consistent leg lengths. The hairpin bending machines

are available with 4, 6 or 8 lines, also in combined versions, with

lengths of the hairpins ranging between 150 and 5000 mm and

diameters ranging between 5 mm (3/16 ") and 16 mm (5/8"). The

standard hairpin bending machine features a 4-axis control; the

fifth axis is optional and can be provided for combined machines.







2.Technical Parameters



ltem

Specification



Model WDLQ-6/8
Max Bending Line 4,6,8 lines
Pipe Diameter mm mm φ5-φ15.88
Thickness Range mm mm 0.25-0.8
Center Distance mm According to the fin drawing
Min Bending Length mm 200
Max Bending Length mm 3000/5000mm
Processing Cycle

≤12S (According to the workpiece lm long)



Feeding Mode Overhead/Eye to Sky or De-reelers
