Automatic Unloading Bending Machine
, Automatic Loading Bending Machine
, Efficiency Automatic Bending Machine
Automatic Bending Machine with Automatic Loading and Unloading System for Efficiency
1. Product Description
Adapted material: steel pipe, stainless steel, copper pipe, aluminum pipe; metal pipe
Recommended application industry: automobile fittings ( oil pipe for brake, muffler, seats),
motorcycle, healthy equipment, air-conditioning, bicycle, steel furniture, sanitary wares and so on.
2. Main specification
1. Automatic recognition of power in machine and work piece, the processing is both quick and good
2. Slow returning core, boosted by barrow, imporving the apprearance of the angle.
3. The whole operation is in the computer, simple, quick and correct
4. Picturized programming system: draw and modify on the stereo pipe image on the screen, makes
the operation simple, quick and correct
5. Rebound test: comparison test on the features of lots of pipe materials
6. Single-step debugging function- a careful observe on the deformation of the pipe material during th
e trail manufacture of dies.
7. Automatic drawing of the graphics of dies-clear help to develop new products
8. Over-all inspection: hydraulic/electrical circuit/ driving systems, absence of phase in motors/inversion,
oltage, temperature, oil pressure, and automatically diagnose the troubles
9. Passwords, keys, working hours/ recordings of quantities, are applied to management of production
3.Technical parameter
| Specification/Model |
Unit |
159NCBA |
Remark |
| Max bending capability round tube |
mm |
Φ159×15 Iron pipe |
1. The Minimum bending radius based on the pipe diameter
2.The Max bending radius can according to the customer’s requirement
3.The Max length of mandrel can according to customer’s requirement |
| mm |
Φ150×10
Stainless steel pipe
|
| Max bending capability square tube |
mm |
150x150x10 Iron pipe |
| mm |
145x145x8
Stainless steel pipe
|
| Max bending radius |
mm |
R800 |
| Min bending radius |
mm |
R60 |
| Max bending angle |
° |
185 |
| Max effective distance of mandrel |
mm |
4800 |
| Control System |
|
NC Control |
| Max elbow bend pipe |
Unit |
32 |
| Max storable sections |
Unit |
16×16 |
| Motor power |
KW |
22 |
| Max. Hydraulic Pressure |
Mpa |
16 |
| Hydraulic System Control |
|
Electromagnetic Valve |
| Oil Tank Capacity |
L |
500 |
| Size |
Cm |
800×245×165 |
| Weight of Machine |
Kg |
≈16000 |
4. Main Mechanical parts
| Name |
Manufacturer |
| Hydraulic Motor |
WUXI TAIHU |
| Hydraulic Valve |
Japan Yuken |
| Over Flow Valve |
Japan Yuken |
| Encoder |
Japan Nemicon |
| Hydraulic Pump |
Wuxi TAIHU |
| Sealing Element |
Shanghai Qifan |
| Contactor |
Schneider |
| Over-Thermal Relay |
Schneider |
| Proximity Switch |
Omron |
| Power Switch |
Taiwan Mingwei |
| Tansformer |
Wuxi Xingyu |
| Oil Tube |
Zhejiang Tongxin |
| Touch screen |
Taiwan Weinview |
| PLC |
Japan Mitsubishi |
