Gas Fired Aluminum Metal Melting Furnace Pipe Burning System Saving Energy 10%

Gas Fired Aluminum Metal Melting Furnace Pipe Burning System Saving Energy 10%

Gas Fired Aluminum Metal Melting Furnace Pipe Burning System Saving Energy 10%
Gas Fired Aluminum Metal Melting Furnace Pipe Burning System Saving Energy 10%

Large Image :  Gas Fired Aluminum Metal Melting Furnace Pipe Burning System Saving Energy 10%

Product Details:
Place of Origin: Jiangsu, China (Mainland)
Brand Name: WONDERY
Certification: CE CERTIFICATE
Model Number: WR-RGQF
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Plywood case suitable for sea transportation
Delivery Time: 30 Days
Payment Terms: L/C, T/T
Supply Ability: 20 Sets per Month
Detailed Product Description
Name: Metal Melting Furnaces Temperature Controller: PID Control
Furnace Type: Stationary Furnace Capacity: 350, 500, 800, 1000kgs
Temperature Control Accuracy: Plus/minus 5 Degree Celsius Max Furnace Temperature: 850 Degree Celcius
High Light:

metal melting machine

,

aluminum melting furnace

                Gas Fired Aluminum Metal Melting Furnace Pipe Burning System Saving Energy

Features

1) The furnace lining is composed of the casting material and the ceramic fiber module material, which has the

    characteristics of good heat preservation effect, small heat storage and fast heating rate. The wall temperature

    rise is ≤ 40℃.

2) The metal melting furnace adopts separation type burning system with PID control, which significantly reduces

    energy consumption. The temperature control accuracy reaches ±5℃.

3)The metal melting furnace is equipped with one thermal couple protected by the silicon nitride outer pipe, and this

  thermal couple could directly measure the aluminum liquid.

4) The furnace adopts European brand graphite crucible, which has a good thermal conductivity,

    a long life, and no iron hyperplasia.

5) The metal melting furnace is equipped with liquid leak alarm, over-temperature alarm and other functions

    to ensure the safety of equipment and operation.

6) The metal liquid is automatically poured out, easy, safe and reliable.



Technical Parameters



Model Crucible Capacity (kg) Melting Capacity (kg/h)

Overall Dimension (mm)

L * W* H

WR-RGQF-350 350 150 1500*1600*1750
WR-RGQF-500 500 200 1670*1700*1800
WR-RGQF-800 800 300 1800*1800*1900
WR-RGQF-1000 1000 400 1800*2100*2400



Advantages of separation pipe burning system:



1) the separation pipe burning system has a lower fault rate, and a low maintenance cost.

2) the separation pipe burning system has a low energy consumption.

3) the separation pipe burning system has a more accurate control of the temperature.



Company Product:
Our company supplies the oil fired or gas fired zinc powder rotary melting furnaces, oil or gas fired zinc powder rotary metal

melting furnace, gas oir oil fired aluminum scrap melting furnaces, reveberatory aluminum melting furnace, continuous aluminum

melting furnae, aluminium melting furnace crucible melting furnace, aluminum liquid transfer ladles, aluminum ladle preheater,

electric aluminium melting furnace, electric aluminium holding furnace, gas fired aluminum holding furnace, box type resistance furnace,

etc.

Crucible melting furnace with pipe burning system is proved to save energy consumption of about 10-20% of fuel consumption. Gas Fired Aluminum Metal Melting Furnace Pipe Burning System Saving Energy 10% 0
