Product Overview

WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD. introduces the WDL-6612 Vacuum High-Temperature Brazing Furnace (Graphite Heating Type) – a production-oriented vacuum brazing system engineered for medium-sized workpieces and batch processing. This furnace features high-quality graphite heating elements combined with a hybrid insulation structure of metal screens and graphite felt, delivering reliable thermal performance at temperatures up to 1300℃ while maintaining operational efficiency.

The WDL-6612 is designed to balance temperature precision with economic operation and user convenience. It is widely adopted for vacuum brazing applications involving copper heat exchangers, stainless steel structural components, and cemented carbide tools.

Technical Specifications

Key Features

• Modular Hot Zone Design: Strategically arranged heating elements simplify maintenance and replacement, reducing total lifecycle costs

• Hybrid Insulation System: Combined graphite felt and metal screen construction balances thermal efficiency with chamber cleanliness requirements

• Extended Working Depth: 1200mm effective zone accommodates longer components or high-volume loading of smaller parts in single batch

• Adjustable Vacuum Range: Flexible vacuum control from 4×10⁻¹ to 8×10⁻³ Pa adapts to different material brazing requirements

• Optimized Cooling Circuit: Internal circulating water cooling design improves heat dissipation and extends furnace service life

• Process Data Management: Control system with USB data export enables convenient parameter tracking and process analysis

• Self-Diagnostic Function: Real-time system monitoring with fault code display facilitates quick troubleshooting and maintenance

Contact WUXI WONDERY INDUSTRY EQUIPMENT CO., LTD. today for detailed technical proposals and pricing information on the WDL-6612 vacuum high-temperature brazing furnace!
